    Bag Making Length 440mm Zipper Bag Making Machine With Three Side Sealing Type

    Zipper Bag Making Machine with three side sealing type


    Product Description:

    The Three Side Sealing & Zipper Machine is a versatile and efficient packaging solution for various types of products. It is specifically designed for the packaging of granular, powder, liquid, and solid products, making it suitable for a wide range of industries such as food and beverage, cosmetics, pharmaceuticals, and more.

    Application:
    The Three Side Sealing & Zipper Machine is perfect for packaging various types of products, including but not limited to:
    • Snack foods
    • Cereals
    • Dried fruits
    • Spices
    • Pharmaceuticals
    • Cosmetics
    • And more!

    Specifications:


    Suitable materialSuitable for various heat sealing composit films
    Tube sizeMax width:1000mm,max diameter:Ф800mm
    Film thickness0.045-0.15mm(single layer)
    Bag making speed

    three side sealing: 250 segments/min,

    Three side zippered bag: 200 segments/min

    Bag making width75-500mm
    Bag making length440mm(longitudinal sealing twice)
    Control systemPLC control system
    Material traction mechanismServo motor system traction
    Discharge systemDischarge shaft,tripod or K frame
    Braking deviceConstant tension encoder magnetic particle control system
    Overall power40kw
    Cooling waterAbout 15L/min
    Air supply0.6Mpa
    Power supplyThree phase 380V/50HZ
    WeightApx5000kgs
    Dimension13×2.×2.2m(L×W×H)
